| Shell Size / 外殼尺寸 | 16 |
|---|---|
| Contacts / 導梢數 | 7 |
| 類型 | Adapter (AD) / 中繼 |
| 類型 | Receptacle (R) / 插座 |
| 品牌 | 錩鋼 |
👋 歡迎光臨！請先登入會員才能購物喔。
立即登入 / 註冊| ❖ No. of contacts | 7 |
|---|---|
| Contacts Configuration |  |
| Rated current / voltage | 5A 125V |
| Operating voltage limit (AC.V.rms) | 200 |
| Withstanding voltage (AC.V.rms) 1 minute | 1000 |
| Insulation resistance (MΩ MIN.) at DC 500V | 1000 |
| Contact resistance (mΩ MAX.) at DC 1A | 3 |
| Solder internal diameter | 0.8 |
