| 型號 | PHM-800 |
|---|---|
| 品牌 | PLT |
👋 歡迎光臨！請先登入會員才能購物喔。
立即登入 / 註冊| 工作台尺寸 | TABLE SIZE | 1350x305mm |
| XYZ軸行程 | X-Y-Z TRAVEL | 800x400x400mm |
| 臥式馬達 | MOTOR | 5HP |
| 臥式主軸錐度 | SPINDLE TAPER | NT40 5/8 or BT40 |
| 臥式主軸轉速 | SPINDLE SPEED | 75-1050 rpm (9段變速) (9-STEP VARIABLE SPEEDS) |
| 臥式主軸中心至工作台面距離 | SPINDLE TO TABLE | 500mm |
| X、Y、Z軸皆使用滾珠螺桿 | BALL SCREW X,Y,Z AXES | |
| 懸吊式操作面板 | SUSPENSION TYPE CONTROL PANEL | |
| 佔地面積 | FLOOR SIZE | 2300x2000mm (含全罩鈑金尺寸) (INCLUDING FULL ENCLOSURE) |
| 電壓 | POWER SUPPLY | 220V/60HZ or (50HZ) |
| LED石英燈 | LED WORK LIGHT |
| 工具箱及工具 | TOOL BOX WITH TOOLS |
| 手動拉桿 (NT40 5/8 or BT40) | MANUAL PULL STUD (NT40 5/8 OR BT40) |
| 前後擋屑皮 (橡膠) | FRONT AND REAR CHIP GUARD (RUBBER) |
| 工作台前鋁檔板 | WORKING TABLE FRONT GUARD |
| 冷卻系統含水盤 | COOLING SYSTEM WITH WATER TRAY |
| 電器箱熱交換器 | HEAT EXCHANGER FOR ELECTRIC CABINET |
| Z軸配重設計 | COUNTER WEIGHT DESIGN Z AXIS |
| 三色工作警示燈 | 3 COLOR ALARM LIGHT |
| 橫軸刀桿 | HORIZONTAL TOOL HOLDER |
| 刀桿支撐座 | TOOL HOLDER SUPPORT |
| 自動潤滑系統 | AUTOMATIC LUBRICATING SYSTEM |
| 地基螺絲及螺帽 | LEVELING BLOCKS AND BOLTS |
| 全罩鈑金 | FULL ENCLOSURE |
| 第四軸分度盤 | 4TH AXIS ROTARY TABLE |
| 控制器 | CONTROLLER |
| 新代或三菱或發那科或西門子 | SYNTEC / MITSUBISHI / FANUC / SIEMENS |
