| 型號 | PHL-30T |
|---|---|
| 品牌 | PLT |
👋 歡迎光臨！請先登入會員才能購物喔。
立即登入 / 註冊| Machine Features | 機器特性 |
| Rugged machine structure presents outstanding stability in high speed machining. Linear motion guides on X, Z axis. High precision ballscrew on X, Z axis. DELTA CNC controlling system is optional (SYNTEC, MITSUBISHI, FANUC, etc.). Spindle spec: A2-3 belt-drive spindle (5000rpm) would be with 4" hydraulic 3-jaw chuck or 5C hydraulic collet chuck. Gang type is our standard model and we could offer the optional functions according to the customer's processing needs. |
整體結構高剛性.加工穩定性優異 X/Z軸配置高剛性滾柱線性滑軌 X/Z軸採用高精度滾珠螺桿 台達 CNC 控制系統，可選配新代、三菱、發那科...等系統 主軸規格: A2-3皮帶主軸 5000rpm 配4吋三爪油壓夾頭或5C油壓筒夾頭 純櫛式為標準機型，可依客戶加工需求選配功能 |
| 技術規格表 Specifications | ||
|---|---|---|
| 項目 Item | 規格 Specification | 數據 Data |
| 機型 | MODEL | PHL-30T |
| 加工範圍 PROCESSING RANGE | ||
| 最大旋徑 | Swing over bed | 500 mm |
| 滑台旋徑 | Swing over slide | 180 mm |
| 最大加工長度 | Max.workpiece length | Φ40 x 120L mm |
| 移動量 MOVE TRAVEL | ||
| X / Z 軸行程 | X / Z axis Travel | 200 x 150 mm |
| X軸快速移動 | X axis rapid | 20000 mm / min |
| Z軸快速移動 | Z axis rapid | 20000 mm / min |
| 主軸 SPINDLE | ||
| 主軸鼻端 | Spindle nose | A2-3 Type |
| 主軸孔徑 | Spindle hole | 34 mm |
| 主軸轉速 | Spindle speed | 5,000 rpm |
| 刀具型式 CUTTING TOOL TYPE A | ||
| 櫛式 (排刀) | Gang type | - |
| 刀把 | Tool shank | □16 / □20 / Φ20 |
| 刀具型式 CUTTING TOOL TYPE B | ||
| 刀塔 | Turret | 8T |
| 刀把 | Tool shank | □16 / □20 / Φ20 |
| 馬達 MOTOR | ||
| 主軸馬達 | Spindle motor | 2.2 kw |
| X 軸馬達 | X axis motor | 0.75 kw |
| Z 軸馬達 | Z axis motor | 0.75 kw |
| 冷卻泵浦 | Coolant pump | 0.35 kw |
| 潤滑泵浦 | Lubricate pump | 0.025 kw |
| 油壓泵浦 | Hydraulic pump | 0.75 kw |
| 油箱容量 OIL TANK CAPACITY | ||
| 潤滑油 | Lubricating oil | 2 L |
| 油壓油 | Hydraulic oil | 44 L |
| 冷卻油 | Coolant | 41 L |
| 動力源 POWER | ||
| 電源 電力 | Electric capacity | 10 KVA |
| 機械尺寸 MACHINE DIMENSIONS | ||
| 外型尺寸 | Machine dimensions | 1440L x 1100W x 1730H mm |
| 機械重量 | Machine weight | 850 kg |
| PHL-30T 標準配備 | PHL-30T Standard Accessories |
|
|
| PHL-30T 選購配備 | PHL-30T Optional Accessories |
|
|
