| Shell Size / 外殼尺寸 | 22 |
|---|---|
| 品牌 | 錩鋼 |
| IP Rating / 防水等級 | IP65 |
| Mil-Spec / 軍規 | MIL-C-5015 |
此商品目前補貨中,請稍後再來。
| Shell Size (ps.2) |
Coupling Threads A | Cable end B ± 0.5 |
Full length L ± 0.8 |
M ± 0.8 | Outer radius Q ± 0.8 |
Rear Threads V | Length of Threads over W |
Length of Connector J ± 0.13 |
|---|---|---|---|---|---|---|---|---|
| WPS3108A 18-10SE |
1-1/8-18UNEF-2B | 15 | 57.4 | - | 34.1 | 1-20UNEF-2A | 10 | 18.7 |
| WPS3108A 22-22SE |
1-3/8-18UNEF-2B | 17 | 74 | - | 40.5 | 1-3/16-18UNEF-2A | 12.5 | 17.2 |
