| 品牌 | 錩鋼 |
|---|---|
| IP Rating / 防水等級 | IP65 |
| Mil-Spec / 軍規 | MIL-C-5015 |
此商品目前補貨中，請稍後再來。
| Shell size (ps.1) |
Coupling Threads A | Cable end B ± 0.3 |
Length of connector J ± 0.3 |
Full length | Outer radius Q ± 0.8 |
Rear Threads V | Length of thread over W |
|---|---|---|---|---|---|---|---|
| 10SL | 5/8-24UNEF-2B | 7 | 13.5 | 46 | 22.2 | 5/8-24UNEF-2A | 9.5 |
| 12S | 3/4-20UNEF-2B | 10.5 | 13.5 | 50.8 | 26.97 | 5/8-24UNEF-2A | 9.5 |
| 14S | 7/8-20UNEF-2B | 12.5 | 13.5 | 54 | 28.6 | 3/4-20UNEF-2A | 9.5 |
| 16 | 1-20UNEF-2B | 15.6 | 18.3 | 65.1 | 31.8 | 7/8-20UNEF-2A | 9.5 |
| 18 | 1-1/8-18UNEF-2B | 18.6 | 18.3 | 68.3 | 34.1 | 1-20UNEF-2A | 9.5 |
| 20 | 1-1/4-18UNEF-2B | 23.0 | 18.3 | 77 | 37.3 | 1-3/16-18UNEF-2A | 9.5 |
| 22 | 1-3/8-18UNEF-2B | 23.2 | 18.3 | 77 | 40.5 | 1-3/16-18UNEF-2A | 9.5 |
| 24 | 1-1/2-18UNEF-2B | 29.6 / 28.0 | 18.3 | 86.5 | 43.7 | 1-7/16-18UNEF-2A | 9.5 |
| 28 | 1-3/4-18UNS-2B | 29.8 / 28.2 | 18.3 | 86.5 | 50 | 1-7/16-18UNEF-2A | 9.5 |
| 32 | 2-18UNS-2B | 35.9 | 18.3 | 95.2 | 56.4 | 1-3/4-18UNS-2A | 11.1 |
| 36 | 2-1/4UN-2B | 43.8 / 42.2 | 18.3 | 100 | 62.7 | 2-18UNS-2A | 12.7 |
