| Shell Size / 外殼尺寸 | 20 |
|---|---|
| 品牌 | 錩鋼 |
| IP Rating / 防水等級 | IP67 |
| Safety Certification / 安規認證 | TÜV |
| RoHS / 歐盟環保指令 | 是 |
此商品目前補貨中，請稍後再來。
相關型號：
[ WPM-20-RF-R ]
[ WPM-20-PM-R ]
[ WPM-20-WGPF2.5-R ]
[ WPM-20-SPM-R ]
[ WPM-20-ADF-R ]
[ WPM-20-WSPM2.5-R ]
[ WPM-20-ADFA-R ]
[ WPM-20-RCa-R ]
| No. of contacts 接點數目 | 2 | 3 | 4 | 7 | 12 |
|---|---|---|---|---|---|
| Contacts Configuration 接點方位 |
 |
 |
 |
 |
 |
| Rated voltage 額定電壓 | 250 V AC | 250 V AC | 250 V AC | 250 V AC | 250V AC |
| Rated Current 額定電流 | 15A | 15A | 15A | 10A | 5A |
| Operation limit voltage (AC.V.rms) 操作電壓限制 | 250 | 250 | 250 | 250 | 250 |
| Withstanding voltage (AC.V.rms) 1 minute 耐電壓1分鐘 | 1500 | 1500 | 1500 | 1500 | 1000 |
| Insulation resistance (MΩ MIN.) at DC 500V 絕緣阻抗 | 2000 | 2000 | 2000 | 2000 | 1000 |
| Contact resistance (mΩ MAX.) at DC 1A 接觸阻抗 | 3 | 3 | 3 | 3 | 5 |
| Solder inner diameter (Φ mm ) 焊孔內徑 | 1.8 | 1.8 | 1.6 | 1.6 | 1.2 |
