迷你臥式CNC加工機 PHM-200

型號	PHM-200
品牌	PLT

歡迎來電或使用表單聯繫我們，將有專員為您服務。

🚚 全館滿1500免運費(超重超材產品不提供滿額免運優惠)
現貨供應中。

「店家保留訂單接受與否權利」
「是否出貨仍會受到實際商品數量、商家成本變動之影響」

機器特性

Machine Features

The same as the general CNC milling machine operation, the work piece can bereplaced after the jig is replaced.
Three-axis fully moving column, modular design, flexible application.
Multi-axis can be processed independently, flexible combination.
The special machine factory can be customized according to the needs of the work piece.
The spindle tool change function can replace the traditional special machine spindle head.
Multiple sets can share one set of jig to reduce costs
Significantly reduce the floor space.
Multi-spindle processing at one time can reduce the work piece process.
It can cooperate with the exchange of worktable to reduce automation costs and reduce the automation difficulty of milling machine.
With the robot arm, it can achieve single-machine automation function.

產品規格 SPECIFICATION

三軸行程	3 Axes Travel
X軸行程	X-axis Travel	300 mm
Y軸行程	Y-axis Travel	200 mm
Z軸行程	Z-axis Travel	200 mm
主軸鼻端至工作台面	Distance From Spindle Nose To Table Surface	170-370 mm
主軸	Spindle	主軸冷卻
主軸轉速	Spindle Speed	12,000 rpm
主軸形式	Spindle Type	直結 Direct-Drive Spindle
主軸端孔斜度	Spindle Nose Taper	BT-30 BT / HSK
主軸馬達 (功率)	Spindle Motor (Continual / 30min)	3.7 / 5.5 KW
進給	Feed Rate
快速位移 (X/Y/Z)	Rapid Traverse (X / Y / Z)	24 / 24 / 24 m/Min
切削位移速度	Cutting Feed Rate	10,000 mm/min
刀庫	Tool Magazine
換刀型式	Tool Change Type	伺服式選刀(刀臂)
刀具數量	Tool Capacity	12 (選配20) set
刀具重量	Tool Weight	3 kgs
最大刀長	Max. Tool Length	200 mm
最大刀直徑	Max. Tool Diameter	60 / 120 mm
刀具交換時間 (T-T)	Tool Change Time (T-T)	1.5 sec
刀具交換時間 (C-C)	Tool Change Time (C-C)	2.5 sec
其他	Other
重量	Weight	4,500kg
重複精度	Repeatability	0.008mm (X / Y / Z)
定位精度	Positioning Accuracy	0.012mm (X / Y / Z)

項目 (中文)	Item (English)	標配 (STD)	選配 (OPD)
全罩式護罩	Fully enclosed splash guard		●
切削液主軸環噴	Coolant jets around spindle	●
主軸中心出水 (CTS)	Coolant through spindle (CTS)		●
直結式主軸	Direct drive spindle	●
電主軸 (30Krpm)	Built-in type spindle (30 K rpm)		●
CNC控制器 / 三菱M80	CNC controller (Mitsubishi M80)		●
PCBase 控制器 (新代科技)	PC-based controller (Syntec)	●
油脂潤滑 (替換式黃油)	Grease lubrication (Replaceable grease)	●
前門自動門	Automatic front door		●
排屑機	Chip conveyor		●
第4軸	4th axis		●
油(氣)壓治具	Hydraulic/pneumatic jig		●
自動化介面	Automation interface		●
變壓器	Tranformer		●
