| Shell Size / 外殼尺寸 | 8 |
|---|---|
| 品牌 | 錩鋼 |
| RoHS / 歐盟環保指令 | 是 |
此商品目前補貨中，請稍後再來。
| ❖ No. of contacts | 4 | 5 | 6 |
|---|---|---|---|
| Contacts Configuration |  |
 |
 |
| Rated current / voltage | 2A 125V | 2A 125V | 2A 125V |
| Operating voltage limit (AC.V.rms) | 125 | 125 | 125 |
| Withstanding voltage (AC.V.rms) 1 minute | 500 | 500 | 500 |
| Insulation resistance (MΩ MIN.) at DC 500V | 1000 | 1000 | 1000 |
| Contact resistance (mΩ MAX.) at DC 1A | 10 | 10 | 10 |
