| Shell Size / 外殼尺寸 | 9 |
|---|---|
| RoHS / 歐盟環保指令 | 是 |
此商品目前補貨中，請稍後再來。
相關型號：
[ PLT-9❖-P-R ]
[ PLT-9❖-R-R ]
[ PLT-9❖-RPCB ]
| No. of contacts | 4 |
|---|---|
| Contacts Configuration |  |
| Rated current / voltage | 1A 300V |
| Operating voltage limit (AC.V.rms) | AC 100V DC 140V |
| Withstanding voltage (AC.V.rms) 1 minute | 300 |
| Insulation resistance (MΩ MIN.) at DC 500V | 200 |
| Contact resistance (mΩ MAX.) at DC 1A | 10 |
| ❖ No. of contacts | 4 | 6 | 7 |
|---|---|---|---|
| Contacts Configuration |  |
 |
 |
| Rated current / voltage | 1A 300V | 1A 300V | 1A 300V |
| Operating voltage limit (AC.V.rms) | 300 | 300 | 300 |
| Withstanding voltage (AC.V.rms) 1 minute | 200 | 200 | 200 |
| Insulation resistance (MΩ MIN.) at DC 500V | 10 | 10 | 10 |
| Contact resistance (mΩ MAX.) at DC 1A | 0.7 | 0.7 | 0.7 |
